Dell PowerEdge Server

Dell PowerEdge Server has the hardware specifications:

  • Intel Xeon E5-2403 1.80GHz, 10M Cache, 6.4GT/s, No tubo, 80W ), Intel C202
  • HDD 500GB 7200 rpm SATA SATA II
  • 2GB 1333MHz RAM (2 x 1GB ) Single Rank UDIMMs/ Matrox G200eW w/ 8Mb memory
  • 1 PCIe x16 G2 slot/ DVD±RW
  • Dell OpenManage™ BMC, IPMI 2.0 compliant Unified Server Configurator Lifecycle Controller PERC H310 Integrated RAID Controller, Raid support: 0,1,5,10,50
  • Form: 1U Rack
  • Single cabled power supply (350W)

Product Description

Dell PowerEdge server rackmount is the best server to implement in SMBs, enterprise for applications.

1. Dell PowerEdge server Processor
Intel Xeon processor E5-2400 and E5-2400 v2 product families
Intel Xeon processor E5-1410
Intel Pentium processor 1400 product family
Processor sockets: 1
Cache: 2.5MB per core; core options: 4, 6, 8, 10
Internal interconnect: Intel DMI 2.0

2. Operating System
Microsoft Windows Server 2012
Microsoft Windows Server 2012 Essentials
Microsoft Windows Server 2008 R2 SP1, x64 (includes Hyper-V)
Novell SUSE Linux Enterprise Server
Red Hat Enterprise Linux
Virtualization options:
Citrix XenServer
VMware vSphere ESXi
Red Hat Enterprise Virtualization

3. Dell PowerEdge server Chipset: Intel C602

4. Memory: Up to 192GB (6 DIMM slots) 2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s

5. Dell PowerEdge server Storage
Maximum internal storage: Up to 16TB
Hard drives:
Hot-plug hard drive options:
2.5” SATA, nearline SAS, SAS (15K, 10K), SAS SSD, SATA SSD, SAS 512n (15K)
3.5” SATA, nearline SAS, SAS (15K)
Cabled hard drive options:
3.5” SATA, nearline SAS, SAS (15K)
Self-encrypting drives available

6. Drive Bays: Up to eight 2.5” or four 3.5″ hot-plug SAS, SATA or SSD

7. Dell PowerEdge server Slots: 2 PCIe slots:
– One x8 PCIe slot with x4 bandwidth, half-length, half-height
– One x16 PCIe slot with x16 bandwidth, half-length, full-height

8. RAID Controllers
Internal controllers:
PERC S110 (SW RAID)
PERC H310
PERC H710
External HBAs (RAID): PERC H810
External HBAs (non-RAID): 6Gbps SAS HBA

9. Network Controller
Embedded NIC: Broadcom® 5720 Dual Port 1Gb LOM
I/O adapter options:
1Gb Ethernet:
– Broadcom 5720 Dual Port 1Gb NIC
– Broadcom 5719 Quad Port 1Gb NIC
– Intel I350 Dual Port 1Gb stand-up adapter
– Intel I350 Quad Port 1Gb stand-up adapter
10Gb Converged Ethernet:
– Brocade® BR1020 Dual Port 10Gb CNA
– QLogic® QLE8262 Dual Port 10Gb DA/SFP+
– Broadcom 57810S Dual Port 10Gb Base-T CNA
– Broadcom 57810S Dual Port 10Gb DA/SFP+ CNA
10Gb Ethernet:
– Intel X520 Dual Port 10Gb DA/SFP+ server adapter
– Intel X540 Dual Port 10Gb Base-T adapter
FC8/FC4 HBA:
– QLogic QLE2460 4Gb Single Port FC HBA
– QLogic QLE2462 4Gb Dual Port FC HBA
– QLogic QLE2560 8Gb Single Port FC HBA
– QLogic QLE2562 8Gb Dual Port FC HBA
– Emulex® LPe-12000-E 8Gb Single Port FC HBA
– Emulex LPe-12002-E 8Gb Dual Port FC HBA
– Brocade 815 8Gb Single Port FC HBA
– Brocade 825 8Gb Dual Port FC HBA

10. Dell PowerEdge server Power
Platinum efficiency, hot-plug, redundant 350W power supply
Bronze efficiency, cabled 350W power supply
Auto-ranging power supplies

11. Availability: High-efficiency, hot-plug, redundant power supplies; hot-plug hard drives; TPM; dual internal SD support; fan fault tolerance; optional bezel; luggage tag; ECC memory, interactive LCD screen; ENERGY STAR® compliant

12. Dell PowerEdge server Chassis: Form factor: 1U rack

13. Management
Remote management
Basic management (default)
iDRAC7 with Lifecycle Controller
iDRAC7 Express (upgrade option), iDRAC7 Enterprise (upgrade option) 8GB or 16GB vFlash media (upgrade options)
Systems management
IPMI 2.0 compliant
Dell OpenManage™ Essentials and Dell Management Console
Dell OpenManage Power Center
Dell OpenManage Connections:
OpenManage Integration Suite for Microsoft® System Center
Dell plug-in for VMware® vCenter™
HP Operations Manager, IBM Tivoli® Netcool®, and CA Network and Systems Management

14. Rack Support
